Typography Task 1/Exercises

4.4.2023-2.5.2023(Week 1-Week

KEBOZHI/0362533

GCD60104/ Typography/ Bachelor of Design (Honours) in Creative  Media

 Task 1:(exercises1&2)


LECTURES

Week 1| Lecture 1

Lecture: Typo_0_Introduction & Briefing
(Typography)
-Typography is the method of creating letter shapes, fonts, and types
(Font)
-Font word comes from French word fount. A font refers to the individual font or weight within the typeface, i.e. Georgia Regular, Georgia Italic and Georgia Bold.

Fig 1.1(13.06.23)

(Typeface)
-A typeface refers to the entire family of fonts/weights that share similar characteristics /styles. i.e. Georgia, Arial, Times New Roman, Didot and Futura.


Week 1:Mr. Vinod introduced this topic in his lecture in the first class and asked us to join a Facebook group. It's for announcements, assignments, files and references that we need to use. I also told you about some software you need to use to do the homework, as well as some teachers' YouTube videos, which include typesetting videos and some tutorials.Mr.Vinod also describes what we need to do for our own electronic portfolio, which will be done in a blog, while explaining its purpose and the reading material we will need to read for further reading.Then Mr.Vinod published our first assignment, which required us to choose 4 words from the 7 words given and design them into our own version. Next, we need to complete a heading.


Lecture:Typo_1_ Typography Development/ Timeline

1.Early letterform development: Phoenician to Roman

fig 0.0 evolution of letterforms from Phoenician alphabet to modern Latin and early Arabic

-Initially writing into wet clay with sharpened stick or carving into stone with a chisel.
-The forms of uppercase letterforms for nearly 2000 years the only letterforms seen to have evolved out of these tools and materials.
- A writing style developed by Greek called ''boustrophedon'' that changed direction of the text read alternatively from right to left and left to right also they changed the orientation of the letterforms.
fig 0.0 Boustropdedon Greek fragment, stone engraving. (Date unknown)


-Etruscan and the roman carvers worked in marble painted letterforms before inscribing them.
fig 0.0 Late 1st century B.C.E., Augustan inscription in Roman Forum, Rome.


fig 0.0 Phoenician to Roman


2.Hand scripts from 3rd-10th century C.E
-In Roman monuments Square capitals can be found found in written version. The letterforms have serifs added to the finish of the main strokes. The variety of stroke width was achieved by the reed pen held at an angle of approximately 60 off the perpendicular.
fig 0.0 4th or 5th century Square Capitals


- A compressed version of square capitals, rustic capitals allowed for  twice as many words on a sheet of parchment and took far less time to write.
-Both square and rustic capitals were reserved for documents of some intended performance. Cursive and simplified for speed.
-Uncia is Latin for a twelfth of anything, Uncials incorporated some aspects of the Roman cursive hand as in the shape of the A, D, E. H, M, U and O.
Fig 0.0 4th century Roman cursive
Fig 0.0 4th- 5th century: Uncials


-Other formalization of the cursive hand , half uncials mark the formal beginning of lowercase letterforms, replete with ascenders and descenders, 2000 years after the origin of Phoenician alphabet.
Fig 0.0 C.500 Half-uncials

-Charlemagne was the first unifier of Europe since the Romans to standardize all ecclesiastical texts issued an edict in 789. The standard for calligraphy set by the monks for a century by rewrote the texts using both majuscules, miniscule, capitalization, and punctuation.
Fig 0.0 C, 925 Caloline miniscule

3.Blackletter to Gutenberg's type
-In Charlemagne's empire the regional variations upon Alcuin's script. Blackletter or texture gained popularity in a condense letterform in northern Europe and in the south ''rotunda'' a rounder more open hand gained popularity. In Italy the humanistic script is based on Alcuin's miniscule.
Fig 0.0 c.1 300: Blackletter (Textura)

-In Gutenberg's skills engineering, metalsmithing , and chemistry are included, and marshaled them all to build pages accurately mimicked the work of the scribe's hand, and his type mold required a different brass matrix , or negative impression, for each letterform.
Fig 0.0 c 1455: line bible, Johann Gutenberg, Mainz

Fig 0.0 c 1455: line bible, Johann Gutenberg, Mainz

Typography development timeline part 1


Typography development timeline part 2

4.Text type classification ( Dates of origin approximated to the nearest quarter century)
-Type forms have developed for in response to prevailing technology, commercial needs, and esthetic trends.

-1450 Blackletter, printing type-based on hand-copying styles used for books in northern Europe. Examples Cloister Black, Goudy Text.
-1475 Oldstyle , lowercase forms used by Italic humanist scholars for book copying and uppercase letterforms on Romans ruins, the forms evolved away from their calligraphic origins over 200 years, across Europe from Italy to England. Examples: Bembo, Caslon, Dante, Garamond, Janson, Jenson, Palatino.
-1500 Italic, Echoing contemporary Italian handwriting, the first italics were condensed and close-set. Since 16th century, virtually all typefaces designed with italic forms.
-1550 Script, Originally and attempt to replicate engraved calligraphic forms, not appropriate in lengthy text settings. In shorter applications, it has wide acceptance. Forms now range the formal and traditional to the casual and contemporary. Examples: Kuenstler Srcipt, Mistral, Sneil Roundhand.
-1750 Transitional, A refinement of oldstyle forms, this style achieved advances in casting and printing, thick to thin exaggerated and brackets were lightened. Example: Baskerville, Bulmer, Century, Time Roman.
-1775 ModernThis style represents a further rationalization of old style letterforms, serifs were unbracketed, contrast between thick and thin. Examples: Bali, Bodoni, Caledonia, Didot, Walbaum.
-1825 Square Serif \ Stab Serif, Originally heavily bracketed serif with little  thick and thin strokes and then developed needs of advertising for heavy type in commercial printing. Example: Clarendon, Memphis, Rockwell, Serifa.
-1900 Sans Serif, the forms were introduced by William Caslon IV in 1816, for example: Akzidenz Grotesk, Grotesk, Gill Sans, Franklin Gothic, Frutiger, Futura, Helvetica, Meta, News Gothic, Optima, Syntax, Trade Gothnic, Univers.
-1990 Serif/ Sans Serif, this style enlarges the notion of a family of typefaces to include both serif and sans serif alphabets often stages between the two. Example: Rotis, Scala, Stone.

Week 2 | Lecture 2:

1.Typography: Text/Tracking :Kerning and Letterspacing
-Kerning - Automatic adjustment of space between letters.
-Letterspacing- The addition of space between letters.
-Tracking- The addition and removal of space in a word or
sentence (Kerning + Letterspacing)
Fig 0.0 Kerning and Letterspacing


2.Normal tracking, loose tracking and tight tracking
-It is important to track words appropriately to make sure   the readability of the word is good.
Fig 0.0 showing 'step' in font univers 55 normal tracking (top right),tight tracking (bottom left)and loose tracking (bottom right)
3.Formating Text:


fig0.0 Normal tracking vs Loose tracking

fig0.0 Tight tracking
Flush left: Each line starts at the same place but ends wherever the last word of the text ends. Spaces between texts are consistent allowing the type to create an even gray value.
gray value- text on a white page
leading- space between each line of text.
fig 0.0 Flush left

Centered text: Imposes symmetry, assigning equal value and weight to both ends of any line.
fig 0.0 centered

Flush right: It emphasis on the end of a line as opposed to its start, used in situations like captions.
fig0.0 Flush right


Justified: Imposes a symmetrical shape on the text and achieved by expanding or reducing spaces between words and sometimes between letters resulting openness of lines can occasionally produce 'rivers' of whit space running vertically.
fig0.0 Justified

This type calls attention to itself before the reader can get to the actual words is simply interference and should be avoided.(Quite simply if you see the words, change the type.)

3. Text / Texture
Different type face suit different messages. A good typographer has to know which typeface best suits the message at hand.
-Text with generous X height or relatively heavy stroke width produces a darker mass on the page (high gray value)
-Text with smaller X height or lighter stroke produces lighter mass on the page(low gray value)
This is Key to making successful layouts
fig0.0 Anatomy of a typeface


Grayscale:
Most suitable gray vale would be a middle gray value such as Baskerville shown below
fig0.0 different type faces and gray values


4. Text/ Leading and Line Length
The goal is setting text type is to allow for easy, prolonged reading and a field of type should occupy the page as much photograph does.
-Type size: Should be large enough to read easily at arm length.
-Leading: Text that is set too tightly encourages vertical eye movement; a reader can easily lose track. Type that is set too loosely creates striped patterns that cause distraction.
-Line length:Shorter lines require less leading; longer lines more. Keep the line length between 55-65 characters. Extremely short or long line lengths impair reading.
fig 0.0 tight leading and short line length on right and loose leading and long line length on left

5. Text/ Type Specimen Book
A type specimen book shows samples of typefaces in various different sizes.
It is to provide an accurate reference for type, type size, type leading, type line length, etc.
Fig 0.0 Sample type specimen sheet


-Compositional requirement: Text should create a field that can occupy a page or a screen.
fig0.0 middle gray value(left), not series of stripes(right)


-Often useful to enlarge type to 400% on the screen to get clear sense of relationship between descenders on one line and ascenders on the line below.

Week 2: Mr.Vinod introduced himself to us and  commented on my classmates' homework than he gave us both general and specific feedback so that we knew what changes should be made to our work.In the end Mr.Vinod also gave us some examples and tutorials on how to modify our works to better express the meaning of words

Week 3 | Lecture 3

6. Text/ Indicating paragraphs
a. 'Pilcrow'- a holdover from medieval manuscripts seldom use today.
Fig 0.0 use of pilcrow

b. ''Line space'' (leading) between lines
12pt leading should have 12pt line spacing as it maintains a good reading rhythm and ensures cross alignment across columns of text.
  fig 0.0 line spacing of 12pts


c. Line space vs leading
Fig 0.0 Line spacing vs Leading

d. Standard indentation
Typically same size as of line spacing of text or same as point size of text
used to save space in newspapers, best used in justified text ( never use for left align otherwise there is ragging on both sides of text).
Fig 0.0 Standard indentation


6.Text/ Window and Orphans
This two are unpardonable gaffes -windows and orphans.
A window is a short line type left alone at the end of a column of text.
A orphan is a short line type of type left alone at the start of new column.
Fig 0.0 Widows and Orphans

In justified text both and orphans are considered serious gaffes. Flush right and ragged left is some what more forgiving towards widows, but only a bit. Orphans remain unpardonable. Only solution to rebreak line endings through out paragraph so that last line of any paragraph is not noticeably short.

7. Text/ Highlighting Text


fig 0.0 Italic/Bold/Color


fig0.0 the sans serif font (univers)has been reduced by.5 to match the x-height of the serif typeface.

fig 0.0 a field of colour



fig 0.0 Quotation marks/ bullets


8. Text/ Headline within Text
-A head indicates clear break between the topics within a section.
fig 0.0 A heads

-B head indicates a new supporting arguments and a subordinate to A heads.
fig 0.0 B heads

- C head highlight specific facets of material within B head text and don't interrupt the flow of reading.
fig 0.0 C heads

9.Text/ Cross Alignment
Cross aligning headlines and captions with text type reinforces the architectural sense of the page - the structure -while articulating the complimentary vertical rhythms.
fig0.0 Cross alignment

Week 3: Mr.Vinod introduced himself to us and  commented on my classmates' homework than he gave us both general and specific feedback so that we knew what changes should be made to our work.In the end Mr.Vinod also gave us some examples and tutorials on how to modify our works to better express the meaning of words.
week 4:General Feedback:Mr.Vinod reviewed the students' homework posted on Facebook and gave some examples, telling us how we could modify our work to make the expression of words clearer.


Week 4 | Lecture 4

Typography: Basic / Describing letterforms

Baseline - Imaginary line the visual base of letterforms
Median Imaginary line defining the x-height of letterforms
X-height - Height in any typeface of the lowercase 'x'

Stroke -
Any line that defines the basic letterform

Apex / Vertex Point created by joining two diagonal stems (apex above and vertex below)

Arm Short strokes off the stem of the letterform, either horizontal (E, F, L) or inclined upward (K, Y)

Ascender - Portion of the stem of a lowercase letterform that projects above the median

Barb Half-serif finish on some curved stroke

Beak - Half-serif finish on some horizontal arms

Bowl - Rounded form that describes a counter (may be open or closed)

Bracket Transition between serif and stem

Cross Bar - Horizontal stroke in a letterform that joins two stems together

Cross stroke - Horizontal stroke in a letterform that joins two stems together

Crotch - Interior space where two strokes meet


Descender - Portion of the stem of a lowercase letterform that projects below the baseline

Ear - Stroke extending out from the main stem or body of the letterform

Em / en - width of an uppercase M (initially), em is now distance equal to the size of the typeface (an em in 48 pts, for example). An en is half the size of an em. Most often used to describe em/en spaceand em/en dashes

Finial
- Rounded non-serif terminal to a stroke

Leg- Short stroke off the stem of the letterform, either at the bottom of the stroke (L) or inclined downward (K, R)

Ligature - Character formed by the combination of two or more letterforms

Link - Stroke that connects the bowl and the loop of a lowercase G

Loop - In some typefaces, the bowl created in the descender of the lowercase g

Spine Curved stem of S

Spur - Extension the articulates the junction of the curved and rectilinear stroke

Stem - Significant vertical or oblique stroke

Stress - Orientation of the letterform, indicated by the thin stroke in round forms

Swash - Flourish that extends the stroke of the letterform
NEVER USE SWASHES IN CAPITAL LETTERS TOGETHER

Tail - Curved diagonal stroke at the finish of certain letterforms

Terminal - Self-contained finish of a stroke without a serif
May be flat ('T' above), flared, acute, ('t' above), grave, concave, convex, or rounded

Typography: Basic/ The font

The full font of a typeface contains much more than 26 letters, to numerals, and a few punctuations marks.
Type family - A family with many different typefaces
Typeface- Individual weight of stroke (Bold, regular, extended, semi bold)
If the type family doesn't have small capitals, don't force it to become a small capital




Small Capitals Uppercase letterforms draw to the x-height of the typeface
Primarily found in serif fonts as part of expert set
Most type software includes a style command that generates small cap based on uppercase forms
Don't confuse real small caps with those artificially generated
Almost always Roman


Uppercase Numerals also called lining figures
Same height as uppercase letters and are all set to the same kerning width
Most successfully used with tabular material or in any situation that calls for uppercase letters


Lowercase Numerals also known as old style figures or text figures
Set to x-height with ascenders and descenders
Best used when you would use upper and lowercase letterforms
Far less common in sans serif type-faces than in serif


Italic Most fonts today are produced with a matching italic
Small caps are almost always only roman
Forms in italic refer beck to fifteenth century Italian cursive handwriting
Oblique are typically based on the roman form of the typeface


Italic vs Roman
Punctuation, miscellaneous characters
Although all fonts contain standard punctuation marks, miscellaneous characters can change from typeface to typeface
Important to be acquainted with all the characters available in a typeface before choosing the appropriate type for a particular job

Ornaments - Used as flourishes in invitations or certificates
Usually are provided as a font in a larger typeface family
Only a few traditional or classical typefaces contain ornamental fonts as part of the entire typeface family (Adobe Caslon Pro)


Typography: Basic/ Describing typefaces

Roman - Letterform is so called as the uppercase forms are derived from inscriptions of Roman monuments
A slightly lighter stroke in roman is known as 'Book'

Italic - Named for fifteenth century Italian handwriting on which the forms are based
Oblique conversely are based on roman form of typeface

Boldface - Characterized by a thicker stroke than roman form
It can be called 'semibold', 'medium', 'black', 'extra bold', or super depending on the relative stroke widths within the typeface
In some typefaces (notable Bodoni), the boldest rendition of the typeface is referred to as 'Poster'

Light - A lighter stroke than the roman form. Even lighter strokes are called 'thin'

Condense - A version of the roman form, and extremely condense styles are often called 'compressed'


Extended - An extended variation of a roman font




Typography: Basic/ Comparing Typefaces
The 10 typefaces represent 500 years of type design. The two goals are easy readability and an appropriate expression of contemporary esthetics

Beyond the gross differences in x-height, the forms display a wealth of variety, in line weight, relative stroke widths and in feeling.
The Rs display a range of attitudes, some whimsical, some stately, some mechanical, others calligraphic some harmonious and some awkward.


Week 5 | Lecture 5

Typography: Letters/ Understanding Letterforms

Fig 0.0 Baskerville 'A'

The uppercase letterforms suggest symmetry, but it is not symmetrical. Two different stroke weights of the Baskerville stroke form; more noteworthy is the fact that each bracket connecting the serif to the stem has a unique arc.
Fig. 0.0 Univers 'A'


The uppercase letter forms may appear symmetrical, but a close examination shows that the width of the left slope is thinner than the right stroke. Both Baskerville (previous) and Univers demonstrate the meticulous care a type designer takes to create letterforms that are both internally harmonious and individually expressive.
Fig. 0.0Helvetica vs Univers

The complexity of each individual letterform is neatly demonstrated by examining the lowercase ‘a’ of two seemingly similar sans-serif typefaces—Helvetica and Univers. A comparison of how the stems of the letterforms finish and how the bowls meet the stems quickly reveals the palpable difference in character between the two.

Typography: Letters/ Maintaining x-height

Fig. 0.0 Median and baseline

X-height: The size of the lowercase letterforms. Curved strokes, such as in ‘s’, must rise above the median (or sink below the baseline) in order to appear to be the same size as the vertical and horizontal strokes they adjoin.

Typography: Letters/ Form/ Counterform

Counterform (or counter)—the space describes, and often contained, by the strokes of the form. When letters are joined to form words, the counterform includes the spaces between them. How well are the counters handled determines how well the words hang together—how easily we can read what’s been set.
Fig. 0.0 Form / Counterform


One of the most rewarding way to understand the form and counter of a letter is to examine them in close detail. the balance between form and counter is achieved and a palpable sense of letterforms's unique characteristics.
Fig 0.0 Helvetica Black, Baskerville


Typography: Letters/ Contrast

The simple contrasts produces numerous variations.

Fig. 0.0 Contrast






INTRUCTIONS


<iframe src="https://drive.google.com/file/d/1WjzT5LKIae31SjTOLkv1-TIA70MIAG8z/preview" width="640" height="480" allow="autoplay"></iframe>
Task 1: Type Expression

We got seven different words from Mr.Vinods, and we had to choose four words for the creative expression. The seven words are speed, crush, melt, blur, dance, throw and kill. Then create pieces that express the meaning of each word.



<iframe src="https://drive.google.com/file/d/164RGS_4226QojmGVLBqFBQD27_q6tvYt/preview" width="640" height="480" allow="autoplay"></iframe>
Fig 1.1(13.06.23)

Fig 1.1(13.06.23)

It is a bit difficult to digitize the sketch because there should be no distortion, so be careful to use the sketchpad to make it better in visual processing, and be careful to control the letter spacing with the simplest design so that it balances out the effect well.
TASK 1 : EXERCISE 2 : TEXT FORMATTING
Exercise 2 We need to design the final style of a word, taking into account the text format of the word, including kerning, line spacing, paragraph spacing, alignment, etc. We need to use Adobe InDesign to build and practice spatial arrangement and information hierarchy skills.
10 type families used in A4 size indesign
Bembo Std
ITC Garamond std
Janson Text Lt Std
Adobe Caslon Pro
Itc New Baskerville Std
Bodoni Std Italic
Serifa std
Futura Std
Gill Sans
Universe Lts std




<iframe src="https://drive.google.com/file/d/15ResGBPudcOp1_H6COn7kBRmV_gQBw2c/preview" width="640" height="480" allow="autoplay"></iframe>
Fig 1.1(13.06.23)


We were asked to choose one of four words to animate, so I chose to pause and slow forward to make the letters look a little more vivid.


<iframe src="https://drive.google.com/file/d/1_V6rvWKb33COlLGsimkiFlP6nokZInS6/preview" width="640" height="480" allow="autoplay"></iframe>

Fig 1.5 process animation BLUR 28.04.2023
Fig 1.5 process animation BLUR 28.04.2023

Fig 1.6 Final GIF BLUR 28.04.2023




<iframe src="https://drive.google.com/file/d/1gzj4_4seaavKlVoXO0sEN9dggyYiMjCC/preview" width="640" height="480" allow="autoplay"></iframe>



<iframe src="https://drive.google.com/file/d/1FQqCICnE8g2nvtvGLqXXjb6FPJdGQEYo/preview" width="640" height="480" allow="autoplay"></iframe>

Fig 2.4 Layout 1 02.05.23

FEEDBACK

WEEK 1:

Mr. Vinod introduced this topic in his lecture in the first class and asked us to join a Facebook group. It's for announcements, assignments, files and references that we need to use. I also told you about some software you need to use to do the homework, as well as some teachers' YouTube videos, which include typesetting videos and some tutorials.Mr.Vinod also describes what we need to do for our own electronic portfolio, which will be done in a blog, while explaining its purpose and the reading material we will need to read for further reading.Then Mr.Vinod published our first assignment, which required us to choose 4 words from the 7 words given and design them into our own version. Next, we need to complete a heading.

WEEK 2:Mr.Vinod introduced himself to us and  commented on my classmates' homework than he gave us both general and specific feedback so that we knew what changes should be made to our work.In the end Mr.Vinod also gave us some examples and tutorials on how to modify our works to better express the meaning of words

WEEK 3:
Our lecturer asked us to post our Text Formatting digitalization works on Facebook for him to comment on as well as give some feedback. Most of us did fine, except for the fact that most of us had problems in terms of text alignment, length, size of text, and readability due to the type of font used and the bad arrangement of text.

WEEK 4:
Mr.Vinods asked us to upload the edited text to Facebook, and he offered some feedback on classmates' work. Let's have problems with text alignment, length, text size, and the reading experience that need to be solved with more appropriate fonts and typography

WEEK 5:
Mr.Vinods asked us to upload the edited text to Facebook, and he offered some feedback on classmates' work. Let's have problems with text alignment, length, text size, and the reading experience that need to be solved with more appropriate fonts and typography.
REFLECTION

HARVEST:
Daily practice every week is not good for English and I have some difficulties. However, through daily search on the Internet and communication with classmates, I have gradually learned a lot of knowledge. I hope I can keep up with the progress in the second stage of learning and finish my works excellently

Observation:
To complete the task of study on time, without delay and without giving up, is the sine qua non of success

Findings:
I learned that the only way to make a good design is to look at smaller details and make more adjustments. Although I am new to this field, I also need to learn to manage my time and put in more effort.


future reading





The author mainly says that he thinks this book can teach professional knowledge of typography and arrangement, and can improve readers' design skills and ideas. This book aims at some interpretation of design methods and understanding of the design profe

评论

此博客中的热门博文
